Small footprint Flex 20 ATE

Flex 20 ATE

The Flex 20 is floor mounted but maintains a small footprint on the shop floor. A VPC S6 interface is normally used on this system allowing multiple test fixtures to be used with the system.

A typical system could consist of

  • Industrial Rack Mount PC with up to 13 expansion slots
  • PXI Chassis up to 18 Slots
  • YAV Relay cards mounted in the VPC Interface
  • In-Circuit Programming Module or JTAG Controller
  • Rack Mount Instruments and Power Supplies

The VPC Interface will take our standard Functional Test Boxes or a Bed of Nails fixtures (CAM or Pneumatically Operated).

Loaded Software can include

  • Teststand – Our Main Operating Environment
  • Flexstand – Easily Create amazing Operator Interfaces
  • Flex Drivers – Simple to use Drivers designed to make programming easy
  • Flex Data Analyser – Get all the statistics on your Logged Test Results
